Product Details:
|
| Advantage: | Fast Linear Motion Control | Body Style: | Cylindrical |
|---|---|---|---|
| Temperature Range: | -20°C To 80°C | Product Usage: | Tow |
| Type: | Electromagnetic | Port Of Loading: | FOB Shenzhen |
| Potenc: | 300gf | Resistance: | At20 ℃ (red And White 13Ω ± 10%) |
| Mounting Type: | Screw | Shape: | Rectangular |
| Duty Cycle: | 50% | Environmental Prot: | ROHS |
| Abient Temp: | -5℃-45℃ | Structure: | Pull Push |
| Port Size: | Can Be Custom |
| Specifications | |||
| Brand | Dason | Product Name | open frame push pull solenoid |
| Model | KS0727 | Rated Voltage | DC 12v |
| Power | 14.4w | Holding Force | 20N |
| Stroke | 6mm | Duty Cycle | 50% |
| Cable Length | 200mm | Material | Metal, Electronic Parts |
| Action Form | Push pull type | Weight(N.W.) | 0.3kg |
| Install Style | Screw | Thread Size & Deepth(mm) | 2-M3 |
| Hi-Pot Test | AC 600V 50/60Hz 2s | Insulation Class | B |
| Packaging Details | |||
| Body Size | 27*19*17(mm) | Carton Box Size(Standard) | 350*310*180(mm), accepted custom |
