Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine

Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine
Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine
Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine

Large Image :  Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine

Product Details:
Place of Origin: China
Brand Name: Dason
Certification: ISO9001
Model Number: XZ3422
Contact Now

Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine

Description
Oem: OK Operating Voltage: 12V
Stroke: 10mm Force: 5N
Specification And Size: Φ30*18（mm） Texture Of Material: Cold Rolled Sheet, Enameled Wire
Type: Electromechanical Holding Force: 10N
Current Characteristics: DC Operating Temperature: 0-60 Degrees Celsius
Weight: 100g Processing Customization: YES
Usage: Safety, Drain, Power: Soft Magnetic Materials
Mounting Type: Flange

This supplier mainly exports to the United States, South Korea, and the Netherlands, and functions as both a manufacturer and trader. The positive review rate is 100.0%, with a total of 15 positive reviews.



Other recommendations for your business

Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine 0

Place of Origin
Guangdong, China
Brand Name
Dason
Technology
Model Number
XZ3422
Type
rotary solenoid
Mounting Type
Threaded installation
Description
DC 12V 24V mini rotary solenoid
Application
fruit sorting equipment
Duty Cycle
25%
Power (Watts)
12w
Voltage - Rated
dc 24v
Size / Dimension
34*22mm
Product name
Rotary Solenoid
Voltage
6VDC/8V DC/12VDC/24VDC
wattage
72w
Diameter
34mm
Size
34*22MM
resistance
48 ohm
Current
0.5A
Tolerance
0.2mm
Service
OEM ODM
Certificate
ISO9001:2015

Customization options

Customized logo (Min. order: 10,000 pieces)
Customized packaging (Min. order: 10,000 pieces)
Graphic customization (Min. order: 10,000 pieces)

The introduction of rotating electromagnets

The introduction of rotating electromagnets is as follows: 1. Voltage: Generally using DC 12V, 24V, 36V, 48V, 110V, 220V
2. Power size:25% energized 12W
3. Temperature resistance level: Under normal circumstances, it defaults to Class B (130 ℃), and can be classified as Class F (155 ℃) and Class H (180 ℃)
4. Torque: Rotating torque can be greater than or equal to 0.03N • M 5. Temperature rise: Normal temperature rise is within 65℃ 6. Service life: typical value is more than 0.3 -2 million times 7. Overall dimensions: diameter 34mm, height 22mm 8. Rotation angle:22°- 45 °, various sizes of angles can be customized, 9. Rotation direction: can be made into clockwise rotation or counterclockwise rotation
Rotary Electromagnet XZ3422 DC 24V Rotation Solenoid 12v Dc Electromagnet Fruit Sorting Machine 1
1. who are we?
We are based in Guangdong, China, start from 2014,sell to North America(35.00%),South Asia(25.00%),Western Europe(20.00%),South America(15.00%),Northern Europe(5.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Electromagnetic devices and parts,electronic component,Hardware accessories,Plastic fitting

4. why should you buy from us not from other suppliers?
Founded in 2014, Our company has rich R&D and manufacturing experience in past 7years,for providing high-tech products, such as rotating electromagnets.We have effectively shorten the customer's time and reduced the customer's cost.

5. what services can we provide?
Accepted Delivery Terms: FOB,DDP,Express Delivery；
Accepted Payment Currency:USD,HKD,CNY;
Accepted Payment Type: T/T,D/P D/A;
Language Spoken:English,Chinese
