Textile Machinery 5mm 20w Automotive Solenoid

I'm Online Chat Now

Textile Machinery 5mm 20w Automotive Solenoid

Textile Machinery 5mm 20w Automotive Solenoid
Textile Machinery 5mm 20w Automotive Solenoid
Textile Machinery 5mm 20w Automotive Solenoid Textile Machinery 5mm 20w Automotive Solenoid Textile Machinery 5mm 20w Automotive Solenoid Textile Machinery 5mm 20w Automotive Solenoid Textile Machinery 5mm 20w Automotive Solenoid

Large Image :  Textile Machinery 5mm 20w Automotive Solenoid

Product Details:
Place of Origin: China
Brand Name: DASON
Certification: ISO9001
Model Number: U0837K-01
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: 3.7USD
Packaging Details: Carton packing
Delivery Time: 30day
Payment Terms: T/T
Supply Ability: 300000

Textile Machinery 5mm 20w Automotive Solenoid

Description
Work Model: Pull Push Type Power: 20w
Size: 08*37mm Application: Textile Machinery
Stroke: 5mm Hi-Pot Tes: AC 600V 50/60Hz 2s
High Light:

20w Automotive Solenoid

,

5mm Automotive Solenoid

,

20w bistable latching solenoid

Product Description



12Mm Stroke Dc Pull Push Open Frame Solenoid



Brand
Dason
Model Number
U0837
Rated Voltage (V)
DC12/24
Rated Power(W)
7.2-72
Work Model
Pull Push Type
Holding Force (N)
1-20
Stroke(mm)
0-12
Reset Time(s)
0.2
Service Life
500 Thousand Times
Certification
CE,ROHS,ISO9001,UL
Material
Iron
Lead Wire Length(mm)
200
Install Style
screw
Tolerance of Dimension
gb/t1804-m
Water-proof
IP65
Insulation Class
B
Hi-Pot Test
AC 600V 50/60Hz 2s
Non-excitation Holding Force
0
Residual Magnefism
/
Duty Cycle
1-100%
Working Temperature
-10°C-100°C
Thread Size(mm)
M3
Thread Depth(mm)
/
Payment Term
TT,PAYPAL
Sample Order
Yes
Warranty
1 Year
MOQ
10 pcs
Supply Ability
5000 pcs per Week
Delivery Time
3 Days
Port of Loading
shenzhen



Product dimension drawing



Textile Machinery 5mm 20w Automotive Solenoid 0

Materials
High quality pure iron house, residual magnetism
High standard copper wire, heating stability, good insulation, efficient conductivity
IP65 waterproof class



Structure
Simple structure design, durable and reliable
Buckle and rubber sleeve parts reduce abrasion, extend service life
Installation and operation
Threaded mounting, easy to install and fix
U-shaped plunger for easy load connection


OEM/ODM is welcome
11 years of designing and producing experience
CE, ROHS, ISO9001, UL certification
Good quality, best service, competitive price
Warmly welcome your visit to our factory


Packaging & Delivery
Packaging Details
Product Size: 27*30*53 (mm)
Carton Box Size: 350*310*180 (mm)
N.W.: 0.3 (KG)
G.W.: 0.4 (KG)
Port:FOB shenzhen

Lead Time :

Quantity(Pieces) 1 - 50 51 - 500 501 - 1000 >1000
Est. Time(days) 5 10 20 To be negotiated
